DRAWER TYPE MAGNETIC GRILL
A permanent magnet drawer type grill is a type of magnetic separator used to remove ferrous metal contaminants from dry and free-flowing products. It consists of a series of magnetic tubes that are mounted on a frame and placed in a hopper made up of SS304/316 or a chute. The product flows through the magnetic tubes, and the ferrous metal contaminants are attracted and held onto the magnetic tubes while the clean product flows out.
The magnetic tubes in the drawer type grill are made up of rare earth magnets, which are very powerful and can attract even weakly magnetic contaminants. The magnetic strength of the magnets is designed to suit the specific application and the amount of ferrous metal contaminants to be removed.
The drawer type grill is easy to clean, and the magnetic tubes can be removed from the frame for cleaning purposes. The cleaned magnetic tubes can be easily reinserted into the frame, making the cleaning process quick and hassle-free.
The permanent magnet drawer type grill is commonly used in industries such as food processing, pharmaceuticals, plastics, and chemicals, where ferrous metal contamination can cause damage to equipment or harm to consumers.
MOST OF TYPES USED IN INDUSTRIES
- SINGLE LAYER TYPE DRAWER GRILL
- DOUBLE LAYER TYPE DRAWER GRILL
- MULTI LAYER TYPE DRAWER GRILL
Low Intensity Drawer Type Magnetic Grill
A low intensity drawer type magnetic grill is a type of magnetic separator that has 2500 Gauss Power which is sufficient to remove weakly magnetic contaminants from dry and free-flowing products.
The magnetic tubes in the low-intensity drawer-type magnetic grill are made up of ceramic magnets, which have lower magnetic strength compared to rare earth magnets.
The low-intensity drawer-type magnetic grill is easy to install and requires minimal maintenance. It is also available in various sizes and configurations, making it suitable for different applications and flow rates.
The low-intensity drawer type magnetic grill is commonly used in industries such as mining, ceramics, and construction, where weakly magnetic contaminants can cause equipment damage or affect the quality of the end product.
Medium Intensity Drawer Type Magnetic Grill
The magnetic tubes in the medium intensity permanent magnet drawer type grill are made up of rare earth magnets, which are very powerful and can attract moderate levels of ferrous metal contaminants. The magnetic strength of the magnets is almost 6000 Gauss & is designed to suit the specific application and the amount of ferrous metal contaminants to be removed.
The medium intensity permanent magnet drawer type grill is easy to clean, and the magnetic tubes can be removed from the frame for cleaning purposes. The cleaned magnetic tubes can be easily reinserted into the frame, making the cleaning process quick and hassle-free.
The medium intensity permanent magnet drawer type grill is commonly used in industries such as food processing, pharmaceuticals, plastics, and chemicals, where moderate levels of ferrous metal contamination can cause damage to equipment or harm to consumers. It is suitable for applications where the level of ferrous metal contamination is not high enough to require a high intensity magnetic separator, but still requires a moderate level of magnetic strength to remove the contaminants.
Overall, the medium intensity permanent magnet drawer type grill offers a balance between magnetic strength and cost-effectiveness, making it a popular choice for a wide range of industrial applications.
High Intensity Drawer Type Magnetic Grill
The magnetic tubes in the high intensity permanent magnet drawer type grill are made up of high-strength rare earth magnets, which are very powerful and can attract even the strongest ferrous metal contaminants. The magnetic strength of the magnets is almost 12,000 Gauss is designed to suit the specific application and the amount of ferrous metal contaminants to be removed.
The high intensity permanent magnet drawer type grill is commonly used in industries such as mining, recycling, and plastics, where high levels of ferrous metal contamination can cause severe damage to equipment or harm to consumers. It is suitable for applications where the level of ferrous metal contamination is too high for a medium or low intensity magnetic separator to handle.
Single Drawer Permanent Magnetic Grills ( High Intensity)
| Model no. | Grill Inlet/Outlet (mm) |
Grill Height (mm) | Drawer Width (mm) | Drawer Length (mm) | No. Of Magnetic Rods | MOC |
|---|---|---|---|---|---|---|
| IMS.SDG.100 | 100 | 165 | 156 | 173 | 3 | SS 304/ SS 316 |
| IMS.SDG.150 | 150 | 165 | 206 | 223 | 4 | SS 304/ SS 316 |
| IMS.SD G.200 | 200 | 165 | 256 | 273 | 5 | SS 304/ SS 316 |
| IMS.SDG.250 | 250 | 165 | 306 | 323 | 6 | SS 304/ SS 316 |
| IMS.SDG.300 | 300 | 165 | 356 | 373 | 6 | SS 304/ SS 316 |
| IMS.SDG.350 | 350 | 165 | 406 | 423 | 7 | SS 304/ SS 316 |
| IMS.SDG.400 | 400 | 165 | 456 | 473 | 8 | SS 304/ SS 316 |
| IMS.SDG.450 | 450 | 165 | 506 | 523 | 9 | SS 304/ SS 316 |
| IMS.SDG.500 | 500 | 165 | 556 | 573 | 10 | SS 304/ SS 316 |
Double Drawer Permanent Magnetic Grills ( High Intensity)
| Model no. | Grill Inlet/Outlet (mm) |
Grill Height (mm) |
Drawer Width (mm) |
Drawer Length (mm) |
No. Of Magnetic Rods | MOC |
|---|---|---|---|---|---|---|
| IMS.DD G.100 | 100 | 250 | 156 | 173 | 5 | SS 304/ SS 316 |
| IMS.DDG.150 | 150 | 250 | 206 | 223 | 7 | SS 304/ SS 316 |
| IMS.DDG.200 | 200 | 250 | 256 | 273 | 9 | SS 304/ SS 316 |
| IMS.DDG.250 | 250 | 250 | 306 | 323 | 11 | SS 304/ SS 316 |
| IMS.DDG.300 | 300 | 250 | 356 | 373 | 13 | SS 304/ SS 316 |
| IMS.DDG.350 | 350 | 250 | 406 | 423 | 13 | SS 304/ SS 316 |
| IMS.DDG.400 | 400 | 250 | 456 | 473 | 15 | SS 304/ SS 316 |
| IMS.DDG.450 | 450 | 250 | 506 | 523 | 17 | SS 304/ SS 316 |
| IMS.DDG.500 | 500 | 250 | 556 | 573 | 17 | SS 304/ SS 316 |
Note:-
The Flanges of inlet/outlet can be customized as per customer’s choice.
The Square / Round Flanges can be provided.
The inlet/outlet can be provided with Triclover Clamps (TC Clamp).
Drawer-type magnetic grills are used in a variety of industries where removing ferrous metal contamination is necessary to protect equipment, improve product quality, and ensure consumer safety. Some of the industries where these magnetic grills are commonly used include:
- Food processing
- Pharmaceutical
- Chemical
- Mining
- Recycling
- Plastics
- Textiles
- Ceramic
- Paints and coatings
- Wood and paper
Q: What is a Drawer Type Magnetic Grill from Industrial Magnetic System and Services?
A: A Drawer Type Magnetic Grill is a type of magnetic separator that is designed to remove ferrous contaminants from dry and free-flowing products. It is installed in the processing line and consists of a series of magnetic tubes that capture and hold magnetic particles as the product flows through the grid.
Q: What are the benefits of using a Drawer Type Magnetic Grill from Industrial Magnetic System and Services?
A: Drawer Type Magnetic Grills are highly effective at removing ferrous contaminants from dry and free-flowing products. They are easy to install and maintain, and can help improve product quality and reduce downtime in processing lines.
Q: Are there any precautions to be taken while handling Drawer Type Magnetic Grills from Industrial Magnetic System and Services?
A: Yes, it is important to follow all recommended safety precautions when handling Drawer Type Magnetic Grills. This includes wearing appropriate personal protective equipment, such as gloves and eye protection, and ensuring that the equipment is not dropped or mishandled during installation or maintenance.
Q: Who should handle Drawer Type Magnetic Grills from Industrial Magnetic System and Services?
A: Drawer Type Magnetic Grills should be handled and installed by trained personnel who are familiar with the specific type of equipment and the hazards associated with handling and installing magnetic equipment. It is important to follow all recommended safety precautions, including wearing appropriate personal protective equipment, when handling Drawer Type Magnetic Grills.
Q: Can people with pacemakers come in contact with Drawer Type Magnetic Grills from Industrial Magnetic System and Services?
A: People with pacemakers or other implanted medical devices should avoid coming into contact with Drawer Type Magnetic Grills or any other magnetic equipment. Magnetic fields can interfere with the proper functioning of pacemakers or other medical devices, which can be dangerous or even life-threatening. If you have a pacemaker or other implanted medical device, you should consult with your doctor before working with or near Drawer Type Magnetic Grills.
Q: How often should Drawer Type Magnetic Grills from Industrial Magnetic System and Services be cleaned and maintained?
A: The frequency of cleaning and maintenance for Drawer Type Magnetic Grills will depend on several factors, including the level of contamination and the specific application. It is generally recommended to clean and inspect Drawer Type Magnetic Grills at regular intervals to ensure optimal performance and longevity. Industrial Magnetic System and Services can provide guidance on the appropriate maintenance requirements for your specific application.
Q: How do I select the appropriate Low, Medium, or High intensity model for my magnetic grill from Industrial Magnetic System and Services?
A: The selection of the appropriate intensity level for your magnetic grill will depend on the specific application and the level of ferrous contamination that needs to be removed. Low-intensity models are typically used for applications with low levels of contamination, while medium and high-intensity models are used for applications with higher levels of contamination. Industrial Magnetic System and Services can provide guidance on the appropriate model for your specific application.
Q: What is the difference between Single, Double, and Multi-layer magnetic grills from Industrial Magnetic System and Services?
A: Single-layer magnetic grills consist of a single row of magnetic tubes, while double-layer and multi-layer magnetic grills have two or more rows of magnetic tubes, respectively. The number of layers will depend on the level of ferrous contamination in the product and the desired level of filtration. Multi-layer magnetic grills are typically used for applications with high levels of ferrous contamination, while single and double-layer magnetic grills are used for applications with lower levels of contamination.
Q: What are the benefits of using a Double or Multi-layer magnetic grill from Industrial Magnetic System and Services?
A: Double or Multi-layer magnetic grills have a higher magnetic strength and can capture more ferrous contaminants compared to single-layer magnetic grills. They are typically used for applications with higher levels of contamination, where a higher level of filtration is required to maintain product quality and reduce downtime.
Q: Can magnetic grills from Industrial Magnetic System and Services be customized to meet specific requirements?
A: Yes, magnetic grills from Industrial Magnetic System and Services can be customized to meet specific requirements, including size, shape, and number of layers. Our experienced team can work with you to design a magnetic grill that meets your exact specifications and requirements.
Q: How often should magnetic grills from Industrial Magnetic System and Services be cleaned and maintained?
A: The frequency of cleaning and maintenance for magnetic grills will depend on several factors, including the level of contamination and the specific application. It is generally recommended to clean and inspect magnetic grills at regular intervals to ensure optimal performance and longevity. Industrial Magnetic System and Services can provide guidance on the appropriate maintenance requirements for your specific application.
Q: Can Drawer Type Magnetic Grills from Industrial Magnetic System and Services be used in wet or corrosive environments?
A: Yes, Drawer Type Magnetic Grills from Industrial Magnetic System and Services can be used in wet or corrosive environments. We offer a range of products with various coatings and materials that can withstand harsh environmental conditions.
Q: Can Drawer Type Magnetic Grills from Industrial Magnetic System and Services be cleaned and maintained easily?
A: Yes, Drawer Type Magnetic Grills from Industrial Magnetic System and Services are designed for easy cleaning and maintenance. The magnetic tubes can be removed easily for cleaning, and the product can be quickly reassembled for use. Regular maintenance can help ensure optimal performance and longevity of the product.
